Atlas AC8000 Rugged Mission Computer
The Atlas AC8000 is a rugged, AI-accelerated mission computer from Cornet’s Atlas series,
purpose-built for defense and aerospace platforms.
purpose-built for defense and aerospace platforms.
Rugged SOSA™ Aligned SBC for Defense & Aerospace
Key Features
Powered by AMD Ryzen Embedded 8000 / Pro 8040 Series (8C/16T) – Up to 5.2 GHz
Integrated AMD Radeon 780M GPU and Ryzen AI NPU supporting up to 16 TOPS
Rugged fanless aluminum enclosure, conduction-cooled
Up to 96 GB DDR5 5600 RAM, ECC/non-ECC options
Up to 3× NVMe PCIe Gen4 x4 high-speed storage
Up to 4× 2.5GbE LAN ports (Intel I226)
Multiple USB ports: USB 4.0, USB 3.2 Gen2, USB 3.2 Gen1
Display output via HDMI 2.1 / DisplayPort 2.1 – up to 8K support
Serial console over USB, fTPM + dTPM support
Wide input voltage support: 12V to 60V DC
Qualified to MIL-STD-810G / DO-160G for harsh environments
10-year guaranteed product availability
Overview
- Housed in a robust, fanless aluminum enclosure, this standalone conduction-cooled system integrates AMD’s latest Ryzen Embedded 8000 Series processor with Radeon 780M GPU and Ryzen AI NPU.
- It delivers up to 16 TOPS of inference performance, enabling real-time edge computing for ISR, UAVs, battlefield management, and autonomous systems.
- Built for long lifecycle programs, the AC8000 offers up to 96 GB DDR5 memory, PCIe Gen4 NVMe storage, and multiple I/O interfaces, all while meeting stringent MIL-STD-810G environmental standards.
Technical Specifications
| Features | Specifications |
| CPU | AMD Ryzen Embedded 8000 / Pro 8040 Series (8C/16T, up to 5.2 GHz) |
| GPU | AMD Radeon 780M |
| AI Accelerator | AMD Ryzen AI NPU – up to 16 TOPS |
| Memory | Up to 96 GB DDR5 5600 MHz (ECC/non-ECC) |
| Storage | Up to 3× NVMe PCIe Gen4 x4 SSDs |
| Networking | Up to 4× 2.5GbE LAN (Intel I226) |
| USB Interfaces | 1× USB 4.0, 1× USB 3.2 Gen2, 3× USB 3.2 Gen1 |
| Display Outputs | Up to 4× HDMI 2.1 / DisplayPort 2.1 (4K/8K support) |
| Console | Serial over USB (Mini USB) |
| Power Input | 12V to 60V DC |
| Enclosure | Fanless, aluminum, rugged construction |
| Dimensions | 300 mm (W) × 250 mm (D) × 82 mm (H) |
| Mounting | Tabletop (custom mounting available) |
| Operating Temp. | -40°C to +85°C (MIL-STD-810G) |
| Storage Temp. | -55°C to +85°C (DO-160G) |
| Humidity | Up to 95% RH @ 40°C (non-condensing) |
| Shock | 40g, 11ms (MIL-STD-810G) |
| Crash Shock | 75g, 11ms (MIL-STD-810G) |
| Vibration | Combined vehicle profiles (MIL-STD-810G) |
| Ingress | Designed for IP67 (dust/sand) |
| Altitude | Operating: up to 30,000 ft; Storage: up to 60,000 ft |
| Compliance |
MIL-STD-810G, DO-160G, VITA 46/65 (VPX), designed for rugged use |
Application Areas
UAVs & Drones
AI-assisted mission computing and sensor fusion
Armoured Ground Vehicles
Tactical edge computing for C4ISR systems
Naval Combat Systems
Rugged compute node for multi-display consoles
ISR & Autonomous Systems
Real-time video analytics, target recognition, and decision-making
